- Title: Carpad T5
- Listed: 02/06/2014 7:52 pm
- ROM Version: ROM Android 4.2.2
You must be logged for ROM download.
8439 total views, 1 today
ROM mobile Carpad T5 - ROM Android 4.2.2
Official ROM Carpad T5 version: 109_v89_carpad_T5_20140115
This ROM is given For 2 version screens different. Look tuto SPMDT for drivers LCD ( XLSSD or T499_49M )
Gapps include – No Rooted
Language support: Multilang
Unpack the archive ********.zip and archive with the ROM
1). Turn off the smartphone. Cable is not connected to the computer.
2). Remove the battery and insert it again
3). Connect your phone to a computer cable. The operating system detects a new device
4). Disconnect the cable from the computer.
5). Run SPMultiPortFlashDownloadProject.exe
6). Choose Database Factory menu> Configuration File data source and specify the file MTK_DATABASE.mdb (it is in the folder SP_MDT).
7). Choose File> Open File Agent download and specify the file MTK_AllInOneDA.bin (it is in the folder SP_MDT).
8). Click File and select the MT6582_Android_scatter_emmc.txt file (it's in the folder with the rom).
9). The other parameters are fixed, as in the screenshot below.
Main sensor = imx111_mipi_raw (back to camera), Sub sensor = ov5648_mipi_raw (front), LCD = XLSSD or T499_49M (display)
10). Click "Start all".
11). Connect your phone to a computer cable. The program should see and blink. If the phone is not detected, then unplug it from the computer, remove and insert the battery and reconnect it to the computer.
12). After (OK) click Stop and disable any phone.
※Please make a backup of your device before installing or updating ROM
