Ulefone
  • Title: W.4G Lenovo S860t
  • Listed: 12/30/2014 7:19 am
  • ROM Version: ROM Android 4.4.3
  • You must be logged for ROM download.



Overall Rating : 10

17125 total views, 4 today

17 Total favorites

2973 Total downloads



W.4G Lenovo S860t
W.4G Lenovo S860t - Image 1W.4G Lenovo S860t - Image 2W.4G Lenovo S860t - Image 3W.4G Lenovo S860t - Image 4W.4G Lenovo S860t - Image 5W.4G Lenovo S860t - Image 6W.4G Lenovo S860t - Image 7

Author adMember Info

nikolaproevski


DESCRIPTION



Hardware : MT6572 (MTK6592 is Fake!)


Model : W.4G


Build number : S5_JB3_3G_QHD_EMMC_32_4_XLD_Z11_ZHUOYUE_2 20140924-143055


Build date UTC : 20140924-063055


Android v : 4.4.3


Baseband v: MOLY.WR8.W1315.MD.WG.MP.V15, 2014/01/04 13:38


Kernel v : 3.4.5 (root@zy-1) (gcc version 4.6.x-google 20120106 (prerelease) (GCC) ) #1 SMP Wed Sep 24 14:28:48 CST 2014


ROM Installation :

1. Download and unpack SP Flash Tool v5.1

2. Load the scatter file

3. After the scatter is loaded hit the download button

4. Connect the phone with the usb to the pc and enter the battery

5. Wait till the download complete

6. Enjoy!


In case after this procedure your phone stuck in boot-loop :

1. Go to Factory Settings (turn off phone and hit the Volume down + Power button at the same time)

2. Inside factory mode choose the 6th option here (e MMC)

3. Wait for this proces to finish and enjoy !


I recomend you to try the new CUSTOM ROM  for this phone :

http://www.needrom.com/download/lenovo-s860t/

NOTE: USE THIS ROM IN CASE YOU HAVE HARDBRICKED YOUR DEVICE BECOUSE IT IS FULL WITH FAKE SPECIFICATION AND CHINESE APPS! THIS IS THE STOCK ROM!



If you have troubles with your phone and need help join this forum :

http://www.china-devices.com/member.php?action=register&referrer=10507


Share Button

※Please make a backup of your device before installing or updating ROM


51 Responses to“W.4G Lenovo S860t”







  1. 12/08/2014
    Posts: 3

    Hello,

    Thank You VERY MUCH for giving us original rom – I looked for this one for a week¨and You are the only one who offers it… Great!

    Can You PLEASE UPLOAD here also SCATTER file? I cann´t make my own as my S860w doesn´t boot to android. I have drivers cleared and updated well under Windows, but in MTK droid tools the phone remains unrecognized.

    But I´m able to get into oŕiginal english bootloader, so I tried to flash Your rom from SD card via the oŕiginal english bootloader as it offers this option (I made it many times on other devices). The process of flashing ROM starts, but after 10 seconds it says : update aborted.

    So I would like to try Your way.

    Thank You very much…



  2. nikolaproevski




    12/29/2014
    Posts: 52

    You will find the scatter file inside the W.4G.zip file : MT6572_Android_scatter_emmc.txt





  3. 12/08/2014
    Posts: 3

    Hello,thank You so much sharing the ROM – I have finaly unbricked my S860w :-)

    It finaly worked, but took 2 days of seeking the internet…

    Perhaps a few advices can help to others:

    most useful video for unbricking – it inspired me also for other china MTK phones to find own solution:

    How to Unbrick every MTK China Phone ! Preloader / SP Flashtool Fix [HD]



    ad 2.  The scatter file is included in ROM, of course – it´s different than flashing from SD card:

    2a. unpack theW.4G.zip in PC and use the scatter file from unpacked folder in Flash tools.

    ad 3. in my Flash tools when I loaded the scatter file, the lines CACHE and USRDATA (the last 2 lines) had empty LOCATION.

    if You experience this:

    3a. unmark these 2 lines before download and probably (or You will get some error message),

    3b. switch to FORMAT in Flash tools and mark "auto format flash", "format the whole flash except boatloader", unplag and re-plug battery and press "start"

    3c. return to "DOWNLOAD", unplug and re-plug battery , leave CACHE and USRDATA lines unmarked, all others marked and press download

    wait some minute, success is green messsage.

    3d. You will need to do 6a in the end.

    4a. connect the phone via USB cable with battery unplagged, enter the download button in Flash tools and plug the battery into phone – You will see download process. If not: install USB drivers properly.

    6a. after You disconnect the phone and try to turn on the phone regularly, it may freeze in bootloap (my phone did).  In this case turn the phone off (unplag battery, plug in back) and

    6b. enter english recovery by pressing "volume plus button"+"on".

    6c. choose WIPE CACHE (choosing just via "volume minus" button and entering the choice via "volume plus" button attention: don´t use  "on" button for enter). Eventually make factory reset. After cache formated and eventually factory reset reboot. (Or – if not possible, unplug and plug battery, turn on regularry)

    7. THE ROM IS CHINESE! Follow the YouTube video to switch to Your language – the ROM is multilingual, fe. I use Czech language and works ok.

    How to change language from chinese to english Android (it´s for 4.0, but similary also works for higher, of course)

    Ok, my s860w is alive again. Hope my experiences may help to someone too.



    Pleaase note, You will be a bit dissapointed, as during the process You will see that Your phone is not in real MTK6592, but just MTK6572. As said in description. But perhaps You know…

  4. nikolaproevski




    12/29/2014
    Posts: 52

    Im glad that you unbricks you phone mate, and nice info of the process! Since i brick my phone twice i thouth that someone else will need this ROM too, btw the ROM is in chinese, but its not problem just change language and you good to go.

  5. nikolaproevski




    12/29/2014
    Posts: 52

    If someone find a better ROM for this phone contact me.







  6. 05/31/2014
    Posts: 2

    Thanks for the rom , is very nice

    battery for mobile, we will find ?

    I can not find another battery for the phone

  7. nikolaproevski




    12/29/2014
    Posts: 52

    The battery on this my phone is piece of s*it. It last max 12h on stand by. But as far as i research the internet for this mobile the produce only 2800mHa, here is a link : http://www.aliexpress.com/item.....44034.html

    Btw the original phone is not lenovo its : Jiake v5.





  8. 01/17/2015
    Posts: 1

    Hello

    I have root access.

    How can I see the 16GB internal ROM?

    I can see only the 1,27GB   sdcard0  partition.

    But I think there are big space about 14,5 GB, there is installed all  the apps.





  9. nikolaproevski




    12/29/2014
    Posts: 52

    You cant see it my friend becouse this phone doesnt have 16GB ROM unfortenatelly.





  10. 01/21/2015
    Posts: 7

    I did also buy this phone  but I dont see the SD card, and the GPS is very week.

    in order to fix the GPS I need to root it do you have any idea how can I root this phone

    I tried this link below but it does not help
