  • Title: Unlock+TWRP+ROOT
  • Listed: 04/29/2016 5:55 pm
  • ROM Version: for Hibook
  • You must be logged for ROM download.



Overall Rating : 2

1714 total views, 2 today

7 Total favorites




Unlock+TWRP+ROOT

Author adMember Info


DESCRIPTION


Hibook-ToolBox




I allowed myself to write a few batch files to help newcomers, as well as other users, under common title "Hibook-Toolbox".

Русскоязычная версия: http://4pda.ru/forum/index.php?s=&showtopic=741766&view=findpost&p=49156807

It allows you to:

Unlock the new tablet Bootloader.

Unprotect system partition from changing (remove "Verity Boot").
Install TWRP-recovery ver-2.8.7.0, which I have ported to this tablet.
Get the correct ROOT in the right way.
Flash custom firmware (which do not have to wait long, I think so)
And other…. I will add if still need to be.



Attention! Whatever you do, you do it at your own risk!



Downloadhttps://onedrive.live.com/redir?resid=15245999D0059D37!50169&authkey=!AFykr0nBKgc12IE&ithint=file%2c7z Updated 06/04/2016




Preparation:

Unzip the archive to PC, but try not to use special characters or folder names with space  in the paths to files. Better way is unzip to a folder in the root of drive C: or D:

Turn on ADB-debugging: "Settings"-"About Tablet" >-> Taps under the item "build number" until the caption appears "you became a developer"-> Return one step back-> enter the item for developers "-> Enable" USB debugging ".
Connect the device to the PC.
Install the Intel driver IntelAndroidDrvSetup1.10.0.exe



Usage:
  • 1.Unlock_Bootloader.bat - Run first. It will unlock the bootloader. Carefully follow the prescriptions of the script and on the screen of the tablet. ATTENTION! All settings, programs, as well as all data on internal SDCard will be destroyed! Data on external MicroSD and Windows will not suffer. After unlocking the device will reboot in native recovery, which does not display anything (stupidly black screen with backlight), the process may take up to 10 minutes (I'm shocked, but it's true), then the device will reboot in Android pristine clean.
  • 2.Unlock_Verity-boot.bat - Run second. It will unlocking the System partition to can be changed. Carefully follow the prescriptions of the script and on the screen of the tablet. The device will reboot. Data on external MicroSD and Windows will not suffer. After all unlock actions, be sure to enter the option for developers and turn ON the item "Factory unlock".
  • 3.Outside_boot-TWRP-recovery.bat - (It is optional. For obtain ROOT access). The device will be rebooted into the temporary session of TWRP-recovery, to Internal sdcard will be placed UPDATE-SuperSU.zip - install it using TWRP. Previously, you can make TWRP backup (recommended!).
  • 4.Flash-TWRP-recovery.bat - (It is optional) TWRP-recovery will be permanently flashed into the Tablet. (Not recommended! Some time firmware will  update, TWRP cannot install OTA-update)
  • 5.Flash-ORIGINAL-recovery.bat - (It is optional) Flash back to the original Recovery.
  • ADB_shell.bat - Just a comfortable CMD-window for ADB-debugging and work with Android Shell.
  • Flash-Custom_FW.bat – My flasher to flash custom firmware, which I am sure will appear in future.



Useful console commands (ADB_shell.bat):
ADB reboot bootloader - reboot to FastbootDroidboot (flashing) mode
ADB reboot recovery - reboot to TWRP or native Recovery mode.
ADB rootrestart ADB-debug service as ROOT.
ADB remount - remounting Android system partition to write (you need root-adb mode see adb root)
ADB shell run Android-console (ash) through which you can run Linux-scripts, internal system commands, etc.
fastboot boot * *.imgrun user-compiled boot.img or recovery.img
fastboot rebootreboot to system from DroidbootFastboot (flashing) mode.
fastboot flash [boot, recovery, system, data] [boot, recovery, system, data]. img - In DroidbootFastboot mode, It will flash specific image to specific partition, example: fastboot flash system c:Custom_FWsystem.img - will flash only system.img to Android system partition.




PS. Under any circumstances, when using TWRP, never do not wipe system partition! Also make sure the TWRP-settings option "Use rm-R instead of formatting is ON  and never leave it. The fact of the matter is that "Verity Boot" marked System partition itself. Withing format the label disappears - the tablet won't boot to Android! This problem can be solved, but why You would make a problem?


If You like may work, buy me a coffee. Please :|


Donate with PayPal to kostyamat

Share Button

※Please make a backup of your device before installing or updating ROM


8 Responses to“Unlock+TWRP+ROOT”







  1. 03/04/2013
    Posts: 46

    cool stuff…thanks for your work!





  2. 02/19/2015
    Posts: 13

    Thanks fit this. Opens up some possibilities.





  3. 08/08/2016
    Posts: 1

    Hello,


    After launching the first .bat file my tablet does not automatically restart. It restarts when I click the power button, and start when the tablet starts normally without data loss as specify

    I attached pictures of my tablet after restarts automatically after launching the .bat file

    What to do ? I am stuck.





  4. 02/19/2015
    Posts: 13

    it didn't wipe my data after the first or second .bat file either, just plough on and follow kostyamats instruction. it all worked out fine for me. Its my first experience with Remix OS, the jurys out at the moment, but essentially it works. Any ideas what the optimum CPU settings are, using Setcpu for example.





  5. 02/19/2015
    Posts: 13

    The jury has returned, love it! Fast and stable and definitely a battery saver. Recommend it to anyone.





  6. 11/25/2015
    Posts: 1

    Hi, sounds good…,

    got my brandnew CHUWI HiBook Pro 2 in 1 Ultrabook Tablet PC today ;-) Could you pls confirm that this tollbox is suitable for this Tablet as well?

    I won´t have to brick it on the very first day using wrong software,

    many thanks in advance

    cheers Andreas







  7. 12/04/2016
    Posts: 1

    can i use this with chuwi vi8
