@echo off

@rem This script is called by x:\Windows\System32\Startnet.cmd – WinPE

@echo.

@echo.

@echo.

@echo Running Intel Optimization powercfg for improved imaging times

@echo.

@echo call powercfg /s 8c5e7fda-e8bf-4a96-9a85-a6e23a8c635c

call powercfg /s 8c5e7fda-e8bf-4a96-9a85-a6e23a8c635c

@echo.

@echo.

@rem

@rem This is the default product key being used:

set productkey=37GNV-YCQVD-38XP9-T848R-FC2HD

@rem

@rem Home/Core: 37GNV-YCQVD-38XP9-T848R-FC2HD

@rem Pro: NF6HC-QH89W-F8WYV-WWXV4-WFG6P

@rem Enterprise: GN7FR-4QK4T-8XPDY-P2RYF-QGP4G

@rem CHN SL: 7B6NC-V3438-TRQG7-8TCCX-H6DDY

@rem SL: NTRHT-XTHTG-GBWCG-4MTMP-HH64C

@echo.

@rem *****************************************************************

@rem List all the disks, then search the volumes of each one to see

@rem which disks may have "Winpe" in the label. We will ignore that

@rem disk and use the first disk without the Winpe label that we find.

@rem *****************************************************************

@echo.>x:\listdisk.txt

@echo list disk>>x:\listdisk.txt

@echo exit>>x:\listdisk.txt

echo x:\listdisk.txt

@echo call diskpart /s x:\listdisk.txt

call diskpart /s x:\listdisk.txt>x:\Disks.txt

@echo.

@rem Set Disk equal to blank to start

set disk=

@echo.

@rem

@rem This line will write a diskpart script to select the disk and detail it's contents.

@rem We use this output to find a disk that does NOT have Winpe as the volume label.

@rem That disk will have the OS installed to it. This way you can exclude USB from diskpart.

@rem

@rem This works around the issue where the USB key is sometimes enumerated as disk 0 and the

@rem SSD is disk 1.

@rem

for /f "skip=8 tokens=2" %%A in (x:\Disks.txt) do (

@echo sel disk %%A>x:\Par.txt

@echo det disk>>x:\Par.txt

@echo exit>>x:\Par.txt

if NOT "%%A"=="DiskPart…" call :ListPar %%A

)

if "%Disk%"=="" echo No disk found without a volume label of "Winpe"&& set disk=0

@echo Using Disk "%Disk%"

@echo.

@echo.

@echo.

@rem *****************************************************************

@rem Detect if System is booted into UEFI mode or Bios mode

@rem *****************************************************************

for /f "tokens=2* delims= " %%A in ('reg query HKLM\System\CurrentControlSet\Control /v PEFirmwareType') do set Firmware=%%B

@echo.

if %Firmware%==0×1 goto :Biosmode

if %Firmware%==0×2 goto :UEFImode

Goto :END

:UEFImode

@echo.

@rem ************************

@rem UEFI SECTION

@rem ************************

@echo The PC is booted in UEFI mode

@echo.>x:\winpart.txt

@echo select disk "%Disk%">>x:\winpart.txt

@echo clean>>x:\winpart.txt

@echo convert gpt>>x:\winpart.txt

@echo create partition efi size=100>>x:\winpart.txt

@echo format quick fs=fat32 label="System">>x:\winpart.txt

@echo assign letter="S">>x:\winpart.txt

@echo create partition msr size=16>>x:\winpart.txt

@echo create partition primary>>x:\winpart.txt

@echo format quick fs=ntfs label="Local Disk">>x:\winpart.txt

@echo assign letter="W">>x:\winpart.txt

@echo shrink desired=800>>x:\winpart.txt

@echo create partition primary>>x:\winpart.txt

@echo format quick fs=ntfs label="Recovery">>x:\winpart.txt

@echo assign letter="R">>x:\winpart.txt

@echo set id="de94bba4-06d1-4d40-a16a-bfd50179d6ac">>x:\winpart.txt

@echo gpt attributes=0×8000000000000001>>x:\winpart.txt

@echo exit>>x:\WinPart.txt

Goto :WINPARTSECTION

:Biosmode

@rem ************************

@rem BIOS SECTION

@rem ************************

@echo The PC is booted in BIOS mode

@echo The PC is booted in BIOS mode>x:\Bios.txt

@echo.>x:\winpart.txt

@echo select disk "%Disk%">>x:\winpart.txt

@echo clean>>x:\winpart.txt

@echo create partition primary size=100>>x:\winpart.txt

@echo active>>x:\winpart.txt

@echo format quick fs=fat32 label="System">>x:\winpart.txt

@echo assign letter="S">>x:\winpart.txt

@echo create partition primary>>x:\winpart.txt

@echo format quick fs=ntfs label="Windows">>x:\winpart.txt

@echo assign letter="W">>x:\winpart.txt

@echo exit>>x:\winpart.txt

@echo.

:WINPARTSECTION

@echo Winpart.txt now contains…..

@echo.

type x:\winpart.txt

@echo.

@echo.

@echo *****************************************************************

@echo Setting up the partition table

@echo *****************************************************************

@echo call diskpart /s x:\winpart.txt

diskpart /s x:\winpart.txt

@echo.

@echo.

@echo *****************************************************************

@rem Map drive letter for Install.wim

@echo *****************************************************************

@echo.>x:\ListVol.txt

@echo List volume>>x:\ListVol.txt

@echo exit>>x:\ListVol.txt

@echo call diskpart /s x:\ListVol.txt

call diskpart /s x:\ListVol.txt>x:\Output.txt

@echo.

@echo.

@rem Go through each drive letter, looking for the images\Install.txt file

for /f "skip=8 tokens=3" %%A in (x:\Output.txt) do (

if exist %%A:\images\install.txt set InstallPath=%%A:\images&& echo "Found device with images folder and install.txt file"

)

@echo.

@echo.

@rem Check InstallPath was found and there are images in it.

if NOT EXIST %InstallPath%\Install.wim echo "Install.wim NOT found." && goto :Error

@echo Install.wim FOUND at %InstallPath%\images\install.wim

@echo.

@echo.

@echo Making directories…

md w:\recycler\scratch

if %errorlevel% NEQ 0 echo "Failed to make w:\recycler\scratch directory" && goto :error

@echo.

md r:\recovery\windowsre

if %errorlevel% NEQ 0 echo "Failed to make m:\recovery\windowsre directory" && goto :error

@echo.

@echo *****************************************************************

@echo Applying the Windows image from the USB

@echo *****************************************************************

@echo call DISM /Apply-Image /ImageFile:%InstallPath%\install.wim /Index:1 /ApplyDir:w:\ /Compact /ScratchDir:w:\recycler\SCRATCH

call DISM /Apply-Image /ImageFile:%InstallPath%\install.wim /Index:1 /ApplyDir:w:\ /Compact /ScratchDir:w:\recycler\SCRATCH

if %errorlevel% NEQ 0 echo "Failed to apply image to w:" && goto :error

@echo.

@echo.

@echo.

@echo *****************************************************************

@echo Add default product key

@echo *****************************************************************

@echo call DISM /Image:w: /Set-ProductKey:%productkey%

call DISM /Image:w: /Set-ProductKey:%productkey%

if %errorlevel% NEQ 0 echo "Failed to set productkey." && goto :error

@echo.

@echo.

@echo.

@echo *****************************************************************

@rem Move WinRE to Recovery Partition

@echo *****************************************************************

@echo.

@echo Modifying attributes of winre.wim so we can move it.

attrib w:\Windows\System32\recovery\winre.wim -s -h -a -r

@echo move w:\Windows\System32\recovery\winre.wim r:\recovery\windowsre

move w:\Windows\System32\recovery\winre.wim r:\recovery\windowsre

if %errorlevel% NEQ 0 echo "Failed to move winre.wim to r:\recovery\windowsre" && goto :error

@echo.

@echo reset attributes now

attrib r:\Recovery\Windowsre\winre.wim +s +h +a +r

@echo.

@echo.

@echo *****************************************************************

@echo Setting the boot environment

@echo *****************************************************************

@echo call w:\WINDOWS\SYSTEM32\BCDBOOT w:\WINDOWS /s s: /f all

w:\WINDOWS\SYSTEM32\BCDBOOT w:\WINDOWS /s s: /f all

if %errorlevel% NEQ 0 echo "Failed to set boot information" && goto :error

@echo.

@echo.

@echo.

@echo *****************************************************************

@echo Setting the recovery environment

@echo *****************************************************************

@echo w:\windows\system32\reagentc /SetREImage /Path r:\RECOVERY\WINDOWSRE /target w:\windows

w:\windows\system32\reagentc /SetREImage /Path r:\RECOVERY\WINDOWSRE /target w:\windows

if %errorlevel% NEQ 0 echo "Failed to set recovery information" && goto :error

@echo.

@echo.

@echo.

@echo *****************************************************************

@echo Copying over Unattend.xml to use on factory floor if it exists

@echo *****************************************************************

@echo if EXIST %WinPESource%Scripts\Unattend.xml copy %WinPESource%Scripts\Unattend.xml w:\Windows\Panther /y

if EXIST %WinPESource%Scripts\Unattend.xml copy %WinPESource%Scripts\Unattend.xml w:\Windows\Panther /y

@echo.

@echo *****************************************************************

@echo Copying over NON Scanstate Packages, if they exist.

@echo IF YOU COPY OVER SCANSTATE PPKG, THIS CAUSE IMAGE TO FAIL DURING RECOVERY

@echo *****************************************************************

@echo if EXIST %WinPESource%Scripts\*.ppkg copy %WinPESource%Scripts\*.ppkg r:\Recovery\Customizations /y

if EXIST %WinPESource%Scripts\*.ppkg copy %WinPESource%Scripts\*.ppkg r:\Recovery\Customizations /y

@echo.

@echo *****************************************************************

@echo Copying over resetconfig.xml and assets, if they exist.

@echo *****************************************************************

@echo if EXIST %WinPESource%Scripts\Recovery\OEM\resetconfig.xml xcopy %WinPESource%Scripts\Recovery\*.* w:\Recovery /e /y

if EXIST %WinPESource%Scripts\Recovery\OEM\resetconfig.xml xcopy %WinPESource%Scripts\Recovery\*.* w:\Recovery /e /y

@echo.

@echo.

@echo *****************************************************************

@echo Copying over LayoutModification.xml and, if it exist.

@echo *****************************************************************

@echo if EXIST %WinPESource%Scripts\LayoutModification.xml copy %WinPESource%Scripts\LayoutModification.xml w:\users\default\appdata\local\Microsoft\Windows\Shell\ /y

if EXIST %WinPESource%Scripts\LayoutModification.xml copy %WinPESource%Scripts\LayoutModification.xml w:\users\default\appdata\local\Microsoft\Windows\Shell\ /y

@echo.

@echo.

@echo.

@echo.

@echo *****************************************************************

@echo Copy over Test tools to \TEST_TOOL

@echo \TEST_TOOL SHOULD BE DELETED PRIOR TO SHIPPING

@echo *****************************************************************

@echo %WinpeSource%Scripts\7za.exe x w:\TEST_TOOL.zip -oW:\

%WinpeSource%Scripts\7za.exe x %WinpeSource%TEST_TOOL.zip -oW:\

if %errorlevel% NEQ 0 echo "Error when run %WinpeSource%Scripts\7za.exe x w:\TEST_TOOL.zip" && goto :error

@echo.

@echo.

@echo *****************************************************************

@echo Copy over Cleanup.cmd link to desktop

@echo *****************************************************************

if EXIST %WinPESource%Scripts\Cleanup.cmd copy %WinPESource%Scripts\Cleanup.cmd w:\Users\Administrator\Desktop /y

@echo.

@echo.

@echo *****************************************************************

@echo Copy over Customer_Test.cmd link to desktop

@echo *****************************************************************

if EXIST %WinPESource%Scripts\Customer_Test.cmd copy %WinPESource%Scripts\Customer_Test.cmd w:\Users\Administrator\Desktop /y

@echo.

@echo.

@echo *****************************************************************

@echo Copy over SMT_Shutdown.cmd link to desktop

@echo *****************************************************************

if EXIST %WinPESource%Scripts\SMT_Shutdown.cmd copy %WinPESource%Scripts\SMT_Shutdown.cmd w:\Users\Administrator\Desktop /y

@echo.

@echo.

@echo *****************************************************************

@echo Copy over SMT_TEST.cmd link to desktop

@echo *****************************************************************

if EXIST %WinPESource%Scripts\SMT_TEST.cmd copy %WinPESource%Scripts\SMT_TEST.cmd w:\Users\Administrator\Desktop /y

@echo.

@echo.

@echo *****************************************************************

@echo.

@echo.

@echo *****************************************************************

@echo Image deployment COMPLETE. Type EXIT from Command

@echo Prompt to restart or turn off device.

@echo *****************************************************************

goto :END

:ERROR

@echo.

@echo An error has been detected.

@echo.

goto :END

:ListPar

@REM This section is to bring a disk number and use it to List Partitions

@echo.

set TempDisk=%1

diskpart /s x:\Par.txt>x:\ParOutput.txt

for /f "skip=26 tokens=4" %%A in (x:\ParOutput.txt) do (

if /i NOT "%%A"=="Winpe" set Disk=%TempDisk%

)

Goto :EOF

:END

@rem

@rem Get finish time so we can evaluate total WinPE phase time.

@rem

call |time>x:\StopTime.txt

@rem

@rem Now parse both files to display the Start and Finish Time

@rem

@echo.

@echo.

for /f "tokens=5" %%A in (x:\starttime.txt) do echo Script Start Time is %%A

for /f "tokens=5" %%A in (x:\stoptime.txt) do echo Script Stop Time is %%A

@echo.
