L861 – HNR-CM13
L861 - HNR-CM13 - Image 1L861 - HNR-CM13 - Image 2L861 - HNR-CM13 - Image 3L861 - HNR-CM13 - Image 4L861 - HNR-CM13 - Image 5L861 - HNR-CM13 - Image 6L861 - HNR-CM13 - Image 7L861 - HNR-CM13 - Image 8L861 - HNR-CM13 - Image 9

Author adMember Info



20180328 build - kernel 3.10.72+ – daily usage – !FOLLOW INSTRUCTIONS FOR GAPPS!

20180401 build - kernel 3.10.72+ – daily usage (Audio Enhancements) – !FOLLOW INSTRUCTIONS FOR GAPPS!

20180405 build – kernel 3.10.72+ – daily usage – already bundled with NANO GAPPS package – NO Need to configure Google Whitelist GSF Device ID (even though still suggested)

20180409 build – kernel 3.10.72+ – daily usage – already bundled with NANO GAPPS package – NO Need to configure Google Whitelist GSF Device ID (even though still suggested) – NFC fully working

0. Disclaimer

The usual stuff :

This package might be most suitable for experienced users but everybody is welcome to use it at his own risk.

Flashing / Rooting your phone and using software tools have risks indeed = if instructions aren't followed you can BRICK YOUR DEVICE. Therefore please read carefully all of the instructions & follow them if You choose to go on at your own risk.

If You don't understand the instructions stop & search on Google/Boards/XDA/etc. and / or ask for help.

All the mentioned software & tools belong to their respective owners/developers. Neither I nor the owners / developers are not to be held responsible if you damage or brick your device.

1. ROM Flashing

HNR-CM13 – CyanogenMOD 13 – Android 6.0.1 Marshmallow for AMOI L861 device (MT6795 – WQHD) – other known re-brands for such phone :

- STONEX ONE #Galileo – #DaVinci – #Dante

- Santin Dante – DaVinci – Marconi

Pre-Requirements :

-          Start from a custom ROM already flashed on the device = FuelOS – PPOS – FlyMEOS . Such ROMs already include custom TWRP recovery 3.0.2 & have unified data storage (while stock firmware uses splitted-data partitioning).


Once ready enter TWRP recovery through ADB or using QuickReboot (requires root).

Once in TWRP :

- Mount System
- Advanced Wipe : Cache / System / Data
- Install zip (choose latest available package)
- Reboot & proceed with initial ROM setup

Then, follow GAPPS instructions to avoid "uncertified device" notice when setting up Google account / services = since March 16th Google has enforced its policies against non-certified devices, that use GAPPS without licensing rights and/or certification status (such as devices running custom roms).


2. GAPPS Installation / configuration :


After you have completed the initial configuration, reboot into TWRP recovery

Install the GAPPS package – you can use provided Full set of OpenGapps

Wipe Cache and Dalvik

Reboot the system

Install the provided DEVICE_ID.APK and run it

Copy the value of Google Service Framework (GSF)

Convert this HEX value to DEC, for example, using an online converter - https://www.binaryhexconverter.com/hex-to-decimal-converter

Open the browser ( on your smartphone or computer ) and go to https://www.google.com/android/uncertified/
- login with the same Google account, that You will use on your smartphone

Enter the DEC value and register. Refresh webpage in order to check everything ok (you'll see ID below).

Reboot your smartphone

Go to Settings Accounts and set up a Google Account


P.S.: Watch .deskclock – latest update 5.2.1 raises SQLiteException DB on HNR-CM13 (20180328 and 20180401).
Go into Settings / App, stop Watch app & clear Data/Cache = it should work fine again.

In case of any new issues with 5.2.1 , downgrade to 5.2 (fully working) :
- Go to Settings \ Applications
- Tap on Watch
- Uninstall updates (top right menu)
then manually upgrade to 5.2.1, installing Watch – Google LLC app from Play Store :
- https://play.google.com/store/apps/details?id=com.google.android.deskclock​

*** CREDITS *** .

Andrea Conficoni (provider of main L861 device for custom ROMs' development & testing) .

- TRONX2100 (Henry) for his hard work & support during last 3 months

bmv1510 (4PDA.ru) for camera / RIL patch

lucky76 (TuttoAndroid.net – aka erlucky on XDA) for his kernel development .

blyha (4PDA.ru) for his CM13 porting on PPTV King7 device .

Team M.A.D. (XDA) for their CM13 porting on Elephone Vowney Lite device

- scafroglia93 (Lorenzo ORI) for his first contribution to L861 kernel sources

※Please make a backup of your device before installing or updating ROM
