• Title: MOTO E XT1022
  • Listed: 05/20/2014 3:14 pm
  • ROM Version: Condor retailsds 4.4.2
  • You must be logged for ROM download.

Overall Rating : 18

19786 total views, 12 today

12 Total favorites

2952 Total downloads


MOTO E XT1022 - Image 1

Author adMember Info



Stock Rom of MOTO E   XT1022  +  How to root with fastboot.

Share Button

※Please make a backup of your device before installing or updating ROM

16 Responses to“MOTO E XT1022”

  1. sameerniyazi

    Posts: 21

    Steps for Flashing

    Steps to restore stock firmware:

    1) Reboot the phone into bootloader mode. There are 2 ways to do this.
    I) The 'hardware' way.
    a) Unplug the USB cable and power off the phone.
     b) Press and hold 'Volume down' then power on the phone.
     c) Connect USB cable to your computer.
    II) The 'software' way.
    a) Enable developer mode on the Moto E (Settings-> 'About Phone'. Tap 7 times on 'Build Number')
     b) Enable USB debugging. (Settings -> 'Developer options' -> 'USB Debugging' -> check)
     c) Connect phone to computer via USB, you should see a new ADB device detected and drivers installed.
     d) Open "Minimal ADB and Fastboot". Type:

    adb reboot-bootloader
    You should see the Moto E bootloader screen with the following options:

    Normal Powerup
    Switch Console [NULL: null]
    BP Tools

    2) Open a command prompt / terminal (Start -> cmd.exe in Win7) and browse to the folder with the extracted firmware.

    cd c:\RETAIL-DSDS_CONDOR_KXC20.82-14_cid7_CFC_1FF

    In windows, run the 'flashall.bat' script Type:

    flashall.bat /eu
    The "/eu" switch forces userdata to be erased from the device, this is the same as a factory reset or wipe this is recommended when restoring stock firmware.

     The scripts will fail with an error on downgrading from 4.4.2 to 4.3. Open the script in a text editor (notepad) and delete (or comment) the following:
     Lines 89-90 in the flashall.bat file:

    CALL :fastboot_flash partition gpt.bin
    IF %errorlevel% NEQ 0 EXIT /b 1
    Lines 120-121 in the flashall.sh file:

    run $fastboot -s "$serial_number" flash partition gpt.bin
    if [ $? -ne 0 ]; then echo "ERROR: fastboot failed."; exit -1; fi
    3b) If you downloaded and extracted a firmware in .xml.zip format.

    Flash each of the partitions in sequence using mfastboot, you need to enter the following commands one-by-one checking that each one returns an [OKAY]

    mfastboot flash partition gpt.bin
    mfastboot flash motoboot motoboot.img
    mfastboot flash logo logo.bin
    mfastboot flash boot boot.img
    mfastboot flash recovery recovery.img
    mfastboot flash system system.img_sparsechunk1
    mfastboot flash system system.img_sparsechunk2
    mfastboot flash system system.img_sparsechunk3
    mfastboot flash modem NON-HLOS.bin
    mfastboot erase modemst1
    mfastboot erase modemst2
    mfastboot flash fsg fsg.mbn
    mfastboot erase cache
    mfastboot erase userdata
    mfastboot reboot

     The 1st command "mfastboot flash partition gpt.bin" will fail on 4.4.2 to 4.3 downgrade.
    Skip this command if you are downgrading and continue with the other commands, which should work.

    4) Wait, you should now be rebooted into a fully stock Moto E firmware.

  2. sameerniyazi

    Posts: 21

    Rooting Instructions

    Procedure to Root Moto E:-
    1.Download the Fastboot package and extract is somewhere on your desktop.
    2.Now move the TWRP recovery to the extracted folder.
    3.Move the Downloaded SuperSu.Zip to your internal storage.
    4.Now reboot your device into bootloader mode by pressing power + volume down for a few seconds.
    5.Now connect your device to your computer with the help of USB Cable.
    6.Navigate to the extracted folder and do a right click + shift and select open command prompt here.
    7.Now type the code in the command window as follows :- Fastboot flash recovery recover image
    8.After that disconnect the device and boot into bootloader mode and use Vol down to select Recovery.
    9.Now its time to Root Moto E.
    10.Select Install Zip from SD Card.
    11.And select the SuperSu you have copied to your Internal storage.
    12.Wait till the installation completes.
    13.After that reboot the device and enjoy root on Moto E.

  3. 05/21/2014
    Posts: 1

    will it be having the original logo.bin with "motorola -a google company" and not "warning bootloader unlocked"


  4. sameerniyazi

    Posts: 21

    Motorola -a google company

  5. sameerniyazi

    Posts: 21



    After downloading the image for your device:


    1. Unzip the image.
    2. Put your device in fastboot mode.
      NOTE: You must use the Motorola fastboot utility to flash (included in the Darwin/, Linux/ or Windows/ directory). Please do NOT use the Android fastboot utility
    3. Follow the flashing steps in the .xml file that was included in the package.
    4. A typical flashing sequence includes all these partitions, but might vary depending on your product – so please use the sequence in the .xml file in your package: $ fastboot flash partition gpt.bin
      $ fastboot flash motoboot motoboot.img
      $ fastboot reboot-bootloader
      $ fastboot flash logo logo.bin
      $ fastboot flash boot boot.img
      $ fastboot flash recovery recovery.img
      $ fastboot flash system system.img
      $ fastboot erase modemst1
      $ fastboot erase modemst2
      $ fastboot flash fsg fsg.mbn
      $ fastboot reboot
      You also have the option to erase all the data on your device with$ fastboot erase userdata
      $ fastboot erase cache
    5. After performing this sequence, you can relock your device with $ fastboot oem lock.

  6. 12/27/2012
    Posts: 24

    Sameer, although my query might be a stupid one… I would like to know if there is a hack to add the 'Auto focus' functionality to the camera ? Wanted to know if this can be transplanted from Moto G ?

    • 09/26/2013
      Posts: 10

      Autofocus is a senario where the camera lens moves back and forth mechanically to focus . So , Unfortunately , No way to convert a fixed focus to auto focus :( . Do try out some camera apps though . you may find a difference .

    • 12/25/2013
      Posts: 1

      Now this is a stupid question… Auto focus is not a software that you can transfer…

  7. 11/13/2014
    Posts: 1

    i need stock rom for my moto e xt1022

    system version : 21.12.40.condor_retaildsds.retaildsdsall.en.03retu

  8. 02/07/2015
    Posts: 1


  9. 02/24/2015
    Posts: 1

    I need official firmware for Moto E XT1022 Dual Sim… Plz someone help me.. Its not there in Motorola's official firmware..

  10. 08/29/2014
    Posts: 1
