Responses to “OUKITEL K4000 Stock Android 5.1”

1.

   03/01/2017




   vlad2017 on 03/13/2018 @ 10:20 am

   Nothing work.

   I tried all rom that i can find for oukitel k4000, even from oukitel download page. Nothing work.

   Something is strange.

   Log in to reply.
2.

   03/01/2017




   vlad2017 on 03/13/2018 @ 9:31 pm

   Hi all!

   We have solved the problem with the uncalibrated screen.
   Need follow two stages:
   Stage 1 – install firmware, install twrp recovery, install root, configure usb debugging on the phone
   Stage 2 – create, modify and upload cfg file using gtpAdbTool

   Files u need:
   1. twrp 2.8.7 for oukitel k4000. U need this because u need to root the phone. Can be found over internet, i will put on google drive.

   2. original firmware from oukitel. I don't try to use other firmware, fell free to try. U can download firmware from here:
   https://www.oukitel.com/latest.....devices-48.html
   I use version OUKITEL_K4000_V7.0_20160216. For some strange reason, link not work when you click on it. Just copy link as text and paste in browser adress bar. Here is link as text: https://mega.nz/#!aA8xlKTD!mt4.....GKO7F_oeBzMy3gc

   3. download sp flash tool SP-Flash-Tool-v5.1532.00.

   4. for your mental sanity, buy an OTG cable. Is terrible to manipulate the phone using touchscreen because is decalibrate. U need to activate usb debugging and with touch decalibrate it's crazy.

   5. download superSU 2.82.

   6. download gdbAdbToolV1.7. U can find on internet.

   7. adb-setup-1.4.3 will install all drivers. I put in my folder and other drivers for windows if u have problems with adb

   All this files u can find on my google drive, if don't want to search over internet.

   Stage 1

   1. install adb-setup. I'm using win7 64bit.

   2. install firmware on phone with spflash tool. Open scatter file from folder with firmware. Power off the phone, remove the battery, connect cable, press start in sp flash tool, then put battery back. Flash will begin. At the end will be an message about succes. U can find on internet how to flash the phone using sp flash tool.

   3. install twrp with sp flash tool. Same procedure like when install firmware, but use scatter file from twrp folder.

   4. root the phone. Put supersu archive on the phone or use an sdcard. Connect otg cable and use an mouse. Boot in recovery mode.

          - power off the phone

         -  press power and volume+. In meniu use volume+ to navigate and volume- to selec. Select recovery.

        - after recovery mode is loaded, navigate to install and select supersu archive.

   5. boot phone normally with otg cable connected, Use mouse to configure developper mode, activate usb debugging, and for your help check option "pointer location". Sometimes u will need to to use touch screen and pointer visualisation will help you. Also, go in supersu app -> settings and check default acces to grant. U don't want to use touch to confirm for access.

   Stage 2

   6. At this stage your phone have clean firmware installed, twrp, is rooted and have options activated for usb debugging. Until now are steps relatively common in phone world, u can find many tutorials over internet. Next u need to read carrefully this post:
   https://forum.xda-developers.c.....-panel-t3302316
   Read few times, follow steps indicate here exactly. Is not too complicate.
   My experience with gtpAdbTool. When i flash new cfg file, give me error, but touchscreen problem is fixed, So ….. be optimistic.
   Also, gtpAdbTool can't read gt9xx_config from phone (permision denied). So i use adb shell and connect as root on my phone and read the file with this command: cat /proc/gt9xx_config
   Copy content and paste int an text editor. I use notepad++

   7. If it helps i put in folder and cfg file that work with my phone. It is not guaranteed that it will work for you, but you can try it. Don't lose anything.
   My phone work perfect now!
   I hope my experience will be of use to you.!

   Here is link from my google drive with all files that u need.: https://drive.google.com/open?.....RKSf00t1owA57cq
