DESCRIPTION
Make sure that you read everything carefully and know what you are doing. Don't blame me for any damage that may occur on your phone.
SP Flash Tool is backward compatible, which means you can (and should) use the most up to date version.
What's needed:
- USB data cable
- MediaTek USB VCOM drivers
- SP Flash Tool (v3.1206.01 or higher for MT6575 / v3.1222.00 or higher for MT6577)
- The Right ROM File from your phone vendor
The tutorial:
- First install SP_Drivers_vx.xxxx.rar for Android
- After, make sure that you have MediaTek DA USB VCOM drivers installed.
- Then in order to flash when you plug in your phone to PC in power off state….you
see a message on your PC, Looking for Drivers “MediaTek MT65xx Preloader”
- Just go to device manager when you see that message….say install drivers manually
and give path to usb2ser_Win7.inf (or other OS) to install the driver.
Flashing the whole ROM
First of all open
SP Flash Tool, then click Scatter-loading button to load the correct scatter
file (MT6575_Android_scatter_emmc.txt or MT6577_Android_scatter_emmc.txt, depending on
which phone you have) for your device and ignore any message that may appear.
Turn off your phone, remove the battery and replace it after some seconds (and don't turn on the phone).
No need for any Fastboot mode, just plug in your phone to PC with USB cable in powered off state for next step
Press F9 (or hit Download button) and connect your phone into the computer via USB data cable. The process will start and a red progress bar will appear.
(You might actually see “Looking for MediaTek MT65xx Preloader” drivers at this step as well…just follow the same step as before to install the VCOM drivers and the flashing process will start)
After the red progress bar is complete, there will appear a purple progress bar.
Right after the purple progress bar is complete, a message will appear underneath it: “
Please insert USB cable in x seconds” and then the download will start right away (you will see the yellow progress bar filling up).
When the yellow bar is complete, you'll get a popup with a green circle and
Download OK message, which means that the process has been successfully terminated.
You can now safely disconnect your phone and turn it on. The process ends here.
Flashing only part with Recovery.img
- In case you want to flash just one part of the ROM, that is also possible. In the shown example, only recovery image will be flashed. Deselect all parts except the one(s) you want to flash and then press F9 (or hit Download button
- The tool will immediately show a warning because not all parts are selected, but you should continue anyway. Safely press Yes to continue.
The download of the chosen partition image will start and after the yellow bar is complete, the popup with the green circle should appear.
Note that, even though it isn't mandatory to select it on the list of images to flash, preloader file must be present in the same folder as the other partition(s) that you want to flash, or else phone will not be able to enter into download mode.
Attention: Please follow the instructions carefully. I
will not take any responsibility on whatever may
happen with your phone.
※Please make a backup of your device before installing or updating ROM
Please help me.
After I followed this steps (I don't know where I went wrong, I must be somewhere) )when I power on my phone it shows two messages in the botom of the screen and last about 20 seconds and the it powers off.
-TOOL DL image Fail!
-uboot is blocking by dl info
Please help. I have a new, recently unbox Lenovo S650
you must tick da dl all with checksum adn try to flash again,
Where I can found the correct scatter file ????
My drivers are installed but it won't connect.
When i go to hardware manager, i can only see Mediatek PreLoader USB VCOM (Android) (COM 5) when i select "show hidden devices". When i select Mediatek PreLoader USB VCOM (Android) (COM 5) it says: Device not connected or no connection.
What can i do about it?
Hello, the same problem I had. With another driver which you can install before I was able to access the smartphone.
Apologies if the translation is not perfect.
In the following link you will be linked to the page with the driver. (tested with Cubot S308)
http://phtechbook.blogspot.de/.....flash-tool.html
i had the same mistake … u must remove the battery and complete the procces if it didnt i have another sollution
make sure you have the vcom drivers instaled properly, take the battery out of your phone go to device manager on your pc put your fingers on power and volume up plug in your usb cable after a few seconds you'll see preloader vcom flash on your screen ,you have to click on it quickly or it dissapears then insert the drivers and thats it .If your on windows 8 or 8.1 the windows 7 drivers work but you have to disable the didgital signatures first just start up your pc in advanced mode and dissable the signatures and restart your pc when you insert the drivers a warning will come up ignore it you'll okay and thats it ready to use flash tools .
nice!
no scatter file after clicking on scatter-loading button…
I have flashed to the new rom. I ve got the "done" circle. I did turn on my phone , check the settings and the rom is the old one. How is it possible?
please someone who have complete backup for stockrom clone s5 mt6571 with scatter txt. please give me link my email jhaveeskie.reign@gmail.com
salve' ragazzi scusatemi qualcuno mi aiuta ho conprato su ebay un clone s5 con carateristiche fasulle di quello che porta sullo scatolo ho messo CPU-Z sul device (tel…) mi esce sta scritta processor exynos samsung octa 5410 2,26 CPU ARM cortex-A15 +ARM cortex -A7 cores 2+4gpu renderer adreno (TM)330 MODEL sm-g900 hardware mt 6572 manufacturer SAMSUNG board MSM8974 android 4.4.2 total ram 2970MB internal storage 15,27GB available storage 1,15GB available RAM1458 MODEL SM -G900 (k3gduosctc) qualcuno mi puo aiutare non trovo niente in giro anche un backup di un telefono lostesso grazie mille'''''''''''''''
hello , boys someone can help me I would like to find a rom for this model and a clone s5 these are the characteristics processor Exynos samsung octa 5410 processor 2,26 ghz architecture ARM cortex A 15+ ARM cortex A7 cores 2+4 GPU render adremo ™330 model sm-g900 HARDWARE MT 6572 manufactuer SAMSUNG BOARD MSM 8974 ANDROID 4.4.2 TOTAL RAM 2970- internal storage 15,27 gb available storage 1,15 gb available RAM1458 -MODELsm-g900 (k3duosctc) help I can not find anything around even a backup of a telephone equal THANK YOU
I wanted to flash the ROM as some of the ROM files got corrupted. However I have downloaded the necessary files as mentioned in your site, and the problem is about installing the drivers. I have checked the comps Device manager there it doens not show any of the drives of VOM or ADB drivers or SP drivers, even tired with show hidden devies, but none, however when the phone is in ON it shows as usual in my comp all the HDD etc. So when I try to flash the ROM it does'nt detect or show the device as connected. Therefore when clicking download F9 it does nothing?
Please help
Thanks
