DESCRIPTION
ROM Mobile Alps H.W T260 – ROM Android 4.2.2
ONLY MT6572
ROM 2 – Add another Official ROM Alps H.W version : ALPS.JB3.MP.V1.2 – t260_td_yl_20140211144353
Based on LeWa_T260_TD_YL_T_14.02.11
ATTENTION This ROM is not compatible with ROM 1
| Software |
SelectShow |
Software Config Table
======================================================
PROJECT NAME : t260_td_yl
PLATFORM : MT6572
BRANCH : SUNMONTECH (W1024)
BUILD VERNO : ALPS.JB3.MP.V1.2
DRAM SIZE :
LCM : nt35510_dsi otm8009_dsi otm8018b_dsi_vdo
TOUCH PANEL : ft5206_sc_GT9XX
BT : MTK_CONSYS_MT6572 = yes
FM : MT6627_FM = yes
WIFI : = yes
GPS : MTK_GPS_MT6572 = no
ALS PS : APDS9930 =
ACCELEROMETER : lis3de_auto_mma8453q_auto
GYROSCOPE :
MAGNETOMETER :
BAROMETER :
MAIN CAMERA : gc2035_yuv , ov2655_yuv
SUB CAMERA : gc0329_yuv ,
FLASH LIGHT : constant_flashlight
LENS : dummy_lens
JOGBALL :
OFN :
======================================================
RF : MT6166_2G_TDD_CUSTOM (sunmontech72_wet_jb3_tdd128hspa_32k_26m_less_nogps)
======================================================
#define CS_PART_NUMBER[0] H9TP32A4GDMCPR_KDM
#define CS_PART_NUMBER[1] KMN5U000ZM_B203
#define CS_PART_NUMBER[2] KE4CN2L2HA5A2A
#define CS_PART_NUMBER[3] H9TP32A4GDBCPR_KGM
#define CS_PART_NUMBER[4] TYC0FH121597RA
#define CS_PART_NUMBER[5] SD7DP24F_4G
#define CS_PART_NUMBER[6] KMN5W000ZM_B207
#define CS_PART_NUMBER[7] SD7DP24C_4G
======================================================
BUILD TIME : 20140211144353
|
————————————————————————————————————————————————————
ROM 1 – Official ROM Alps H.W version : ALPS.JB3.MP.V1.2 – t260_td_yl_3g_20131204182237
This mobile is fake huawei i don't know exactly the model.
Based on LeWa_T260_TD_YL_13.12.04
| Software |
SelectShow |
Software Config Table
======================================================
PROJECT NAME : t260_td_yl
PLATFORM : MT6572
BRANCH : SUNMONTECH (W1024)
BUILD VERNO : ALPS.JB3.MP.V1.2
DRAM SIZE :
LCM : nt35510_dsi otm8009_dsi otm8018b_dsi_vdo
TOUCH PANEL : ft5206_sc_GT9XX
BT : MTK_CONSYS_MT6572 = yes
FM : MT6627_FM = yes
WIFI : = yes
GPS : MTK_GPS_MT6572 = no
ALS PS : APDS9930 =
ACCELEROMETER : lis3de_auto_mma8453q_auto
GYROSCOPE :
MAGNETOMETER :
BAROMETER :
MAIN CAMERA : gc2035_yuv ,
SUB CAMERA : gc0329_yuv ,
FLASH LIGHT : constant_flashlight
LENS : dummy_lens
JOGBALL :
OFN :
======================================================
RF : MT6166_2G_TDD_CUSTOM (sunmontech72_wet_jb3_tdd128hspa_32k_26m_less_nogps)
======================================================
#define CS_PART_NUMBER[0] H9TP32A4GDMCPR_KDM
#define CS_PART_NUMBER[1] KMN5U000ZM_B203
#define CS_PART_NUMBER[2] KE4CN2L2HA5A2A
#define CS_PART_NUMBER[3] H9TP32A4GDBCPR_KGM
#define CS_PART_NUMBER[4] TYC0FH121597RA
#define CS_PART_NUMBER[5] SD7DP24F_4G
#define CS_PART_NUMBER[6] KMN5W000ZM_B207
#define CS_PART_NUMBER[7] SD7DP24C_4G
======================================================
BUILD TIME : 20131204173150
|
Gapps not include – no Rooted
Language support: EN/CN/TW
ROM Install :
- Unpack FlashTools, and Click on Flash_tool.exe
- Select a the MT6572_Android_scatter.txt in ROM
- Wait file to be added into Flash Tool
- choose Option->USB Model,click USB Model
–> Choose Option->DA DownLoad All->Speed->High Speed, click High Speed
- Turn off your phone, remove the battery.
- "Press F9 (hit Download button)" OR " if upgrade ROM Firmware->Upgrade "
- and connect your phone into the computer via USB data cable.
- The process will start and a red progress bar will appear after color purple, yellow.
- And green circles display
- Finish !
- You can now safely disconnect your phone and turn it on.
※Please make a backup of your device before installing or updating ROM
