oem unlock
flash oemvars oemvars.txt
flash gpt gpt.bin
flash bootloader bootloader
oem rm /ESP/BIOSUPDATE.fv
flash ifwi afu.bin
erase misc
erase persistent
erase metadata
format config
format cache
flash system system.img
flash boot boot.img
flash recovery recovery.img
oem verified
format data
continue

@echo off
@rem  This script is called by x:\Windows\System32\Startnet.cmd – WinPE
@echo.
@echo.
@echo.
@echo.
@rem  *******************************************************************
@rem  FLASH_BIOS=1 Auto flash BIOS / FLASH_BIOS=0 Do not auto flash BIOS
@rem  *******************************************************************
@echo.

set FLASH_BIOS=0

@echo.
@echo Running Intel Optimization powercfg for improved imaging times
@echo.
@echo call powercfg /s 8c5e7fda-e8bf-4a96-9a85-a6e23a8c635c
call powercfg /s 8c5e7fda-e8bf-4a96-9a85-a6e23a8c635c
@echo.
@echo.
@echo.
@rem  *****************************************************************
@rem  List all the disks, then search the volumes of each one to see
@rem  which disks may have "Winpe" in the label. We will ignore that
@rem  disk and use the first disk without the Winpe label that we find.
@rem  *****************************************************************
@echo.>x:\Listdisk.txt
@echo list disk>>x:\Listdisk.txt
@echo exit>>x:\Listdisk.txt
@echo call diskpart /s x:\Listdisk.txt
call diskpart /s x:\Listdisk.txt>x:\Disks.txt
@echo.
@rem Set Disk equal to blank to start
set disk=
@echo.
@rem
@rem  This line will write a diskpart script to select the disk and detail it's contents.
@rem  We use this output to find a disk that does NOT have Winpe as the volume label.
@rem  That disk will have the OS installed to it. This way you can exclude USB from diskpart.
@rem
@rem  This works around the issue where the USB key is sometimes enumerated as disk 0 and the
@rem  SSD is disk 1.
@rem
for /f "skip=8 tokens=2" %%A in (x:\Disks.txt) do (
@echo sel disk %%A>x:\Par.txt
@echo det disk>>x:\Par.txt
@echo exit>>x:\Par.txt
if NOT "%%A"=="DiskPart…" call :ListPar %%A
)
if %Disk%=="" echo No disk found without a volume label of "Winpe"&& set disk=0
@echo Using Disk "%Disk%"
@echo.
@echo *****************************************************************
@rem  Map drive letter for Install.wim and Winre.wim
@echo *****************************************************************
@rem Create an output file containing all the drive letters
@echo.>x:\listVol.txt
@echo list volume>>x:\listVol.txt
@echo exit>>x:\listVol.txt
@echo call diskpart /s x:\listVol.txt
call diskpart /s x:\Listdisk.txt>x:\Output.txt
@echo call diskpart /s x:\listVol.txt>x:\Output.txt
diskpart /s x:\listVol.txt>x:\Output.txt
@echo.
@rem Go through each drive letter, looking for the images\Install.txt file
for /f "skip=8 tokens=3" %%A in (x:\Output.txt) do (
if exist %%A:\images\install.txt set InstallPath=%%A:\images&& echo "Found device with images folder and install.txt file"
)
@echo.
@echo.
@echo.
@echo *****************************************************************
@echo  Checkup SingleOS or DualOS or whether exist windows partiton
@echo *****************************************************************
@rem create diskpart script for search windows partitions from emmc disk
@echo.>x:\ListPar.txt
@echo select disk "%Disk%" >>x:\ListPar.txt
@echo list partition >>x:\ListPar.txt
@echo exit >>x:\ListPar.txt
@echo.
@rem run diskpart script
diskpart /s x:\ListPar.txt >x:\eMMCPar.txt
@echo.
@rem SingleOS / DualOS switch
find "Partition 6" x:\eMMCPar.txt >nul
if %ERRORLEVEL% NEQ 0 Goto :SingleOS
@rem ensure it's DualOS,and check whether exist windows partition,if not:create the new windows partition
find "Partition 12" x:\eMMCPar.txt >nul
if %ERRORLEVEL% NEQ 0 Goto DualOS
@echo.>x:\checkpart.txt
@echo select disk "%Disk%">>x:\checkpart.txt
@echo list partition>>x:\checkpart.txt
@echo exit>>x:\checkpart.txt
@echo call diskpart /s x:\checkpart.txt>x:\outpar.txt
call diskpart /s x:\checkpart.txt>x:\outpar.txt
@echo.
@echo.>x:\DelPar.txt
@echo select disk "%Disk%">>x:\DelPar.txt
for /f "skip=21 tokens=2" %%A in (x:\outpar.txt) do (
 if %%A NEQ DiskPart… echo select partition %%A>>x:\DelPar.txt && echo delete partition override>>x:\DelPar.txt
)
echo exit>>x:\DelPar.txt
diskpart /s x:\DelPar.txt
Goto DualOS

:SingleOS
@echo.
@echo           This is a SingleOS!
@echo.
@echo.
:UEFImode
@echo.
@rem ************************
@rem UEFI SECTION
@rem ************************
@echo The PC is booted in UEFI mode
@echo.>x:\winpart.txt
@echo select disk "%Disk%">>x:\winpart.txt
@echo clean>>x:\winpart.txt
@echo convert gpt>>x:\winpart.txt
@echo create partition efi size=100>>x:\winpart.txt
@echo format quick fs=fat32 label="System">>x:\winpart.txt
@echo assign letter="S">>x:\winpart.txt
@echo create partition msr size=16>>x:\winpart.txt
@echo create partition primary>>x:\winpart.txt
@echo format quick fs=ntfs label="Windows">>x:\winpart.txt
@echo assign letter="W">>x:\winpart.txt
@echo shrink desired=800>>x:\winpart.txt
@echo create partition primary>>x:\winpart.txt
@echo format quick fs=ntfs label="Recovery">>x:\winpart.txt
@echo assign letter="R">>x:\winpart.txt
@echo set id="de94bba4-06d1-4d40-a16a-bfd50179d6ac">>x:\winpart.txt
@echo gpt attributes=0×8000000000000001>>x:\winpart.txt
@echo exit>>x:\WinPart.txt
@echo Winpart.txt now contains…..
@echo.
type x:\winpart.txt
@echo.
@echo.
@echo *****************************************************************
@echo  Setting up the partition table
@echo *****************************************************************
@echo call diskpart /s x:\winpart.txt
diskpart /s x:\winpart.txt
@echo.
@echo.
@echo.
@echo.
@rem Check InstallPath was found and there are images in it.
if NOT EXIST %InstallPath%\Install.wim echo "Install.wim NOT found." && goto :Error
@echo Install.wim FOUND at %InstallPath%\images\install.wim
@echo.
@echo.
@echo.
@echo *****************************************************************
@rem  Switches to the USB disk
@rem  Create folders on local (eMMC) disk and copy files from USB disk
@echo *****************************************************************
@echo.
@echo Making directories…
md w:\recycler\scratch
if %errorlevel% NEQ 0 echo "Failed to make w:\recycler\scratch directory" && goto :error
@echo.
md r:\recovery\windowsre
if %errorlevel% NEQ 0 echo "Failed to make m:\recovery\windowsre directory" && goto :error
@echo.
@echo.
@echo *****************************************************************
@echo  Applying the Windows image from the USB
@echo *****************************************************************
@echo call dism /apply-image /imagefile:"%InstallPath%\Install.wim" /index:1 /applydir:w:\ /compact /scratchdir:"w:\recycler\SCRATCH
call dism /apply-image /imagefile:"%InstallPath%\Install.wim" /index:1 /applydir:w:\ /compact /scratchdir:"w:\recycler\SCRATCH
if %errorlevel% NEQ 0 echo "Failed to apply image to w:" && goto :error
@echo.
@echo *****************************************************************
@echo  Rund SingleInstance
@echo *****************************************************************
@echo.
if EXIST W:\Recovery\Customizations\USMT.ppkg dism /Apply-CustomDataImage /CustomDataImage:W:\Recovery\Customizations\USMT.ppkg /ImagePath:W:\ /SingleInstance
@echo *****************************************************************
@rem  Move WinRE to Recovery Partition
@echo *****************************************************************
@echo.
@echo Modifying attributes of winre.wim so we can move it.
attrib w:\Windows\System32\recovery\winre.wim -s -h -a -r
@echo move w:\Windows\System32\recovery\winre.wim r:\recovery\windowsre
move w:\Windows\System32\recovery\winre.wim r:\recovery\windowsre
if %errorlevel% NEQ 0 echo "Failed to move winre.wim to r:\recovery\windowsre" && goto :error
@echo.
@echo reset attributes now
attrib r:\Recovery\Windowsre\winre.wim +s +h +a +r
@echo.
@echo.
@echo *****************************************************************
@echo  Setting the boot environment
@echo *****************************************************************
@echo call w:\WINDOWS\SYSTEM32\BCDBOOT w:\WINDOWS /s s: /f all
w:\WINDOWS\SYSTEM32\BCDBOOT w:\WINDOWS /s s: /f all
if %errorlevel% NEQ 0 echo "Failed to set boot information" && goto :error
@echo.
@echo.
@echo.
@echo *****************************************************************
@echo  Setting the recovery environment
@echo *****************************************************************
@echo w:\windows\system32\reagentc /SetREImage /Path r:\RECOVERY\WINDOWSRE /target w:\windows
w:\windows\system32\reagentc /SetREImage /Path r:\RECOVERY\WINDOWSRE /target w:\windows
if %errorlevel% NEQ 0 echo "Failed to set recovery information" && goto :error
@echo.
@echo.
@echo.
@echo.
attrib +H +R W:\Recovery
rmdir /s /q w:\recycler
if "%FLASH_BIOS%"=="1" GOTO :FLASH_BIOS
@echo *****************************************************************
@echo  WIMboot image deployment COMPLETE. Type EXIT from Command
@echo  Prompt to restart or turn off device.
@echo *****************************************************************
Wpeutil shutdown
color 2f
Goto :END

DualOS
@echo.
@echo           This is a DualOS!
@echo.
@echo.
@echo *****************************************************************
@echo  Write the diskpart script now that we know what disk to use
@echo *****************************************************************
@echo.>x:\winpart.txt
@echo select disk "%Disk%">>x:\winpart.txt
@echo select volume "0">>x:\winpart.txt
@echo attributes volume set hidden>>x:\winpart.txt
rem @echo select volume "1">>x:\winpart.txt
rem @echo attributes volume set hidden>>x:\winpart.txt
@echo create partition efi size=100>>x:\winpart.txt
@echo format quick fs=fat32 label="System">>x:\winpart.txt
@echo assign letter="S">>x:\winpart.txt
@echo create partition msr size=16>>x:\winpart.txt
@echo create partition primary>>x:\winpart.txt
@echo format quick fs=ntfs label="Windows">>x:\winpart.txt
@echo assign letter="W">>x:\winpart.txt
@echo shrink desired=800>>x:\winpart.txt
@echo create partition primary>>x:\winpart.txt
@echo format quick fs=ntfs label="Recovery">>x:\winpart.txt
@echo assign letter="M">>x:\winpart.txt
@echo set id="de94bba4-06d1-4d40-a16a-bfd50179d6ac">>x:\winpart.txt
@echo gpt attributes=0×8000000000000001>>x:\winpart.txt
@echo exit>>x:\WinPart.txt
@echo.
@echo winpart.txt now contains…..
@echo.
type x:\winpart.txt
@echo.
@echo.
@echo *****************************************************************
@echo  Setting up the partition table
@echo *****************************************************************
@echo call diskpart /s x:\winpart.txt
diskpart /s x:\winpart.txt
@echo.
@echo.
@echo.
@echo.
@rem Check InstallPath was found and there are images in it.
if NOT EXIST %InstallPath%\Install.wim echo "Install.wim NOT found." && goto :Error
@echo Install.wim FOUND at %InstallPath%\install.wim
@echo.
@echo.
@echo.
@echo *****************************************************************
@rem  Switches to the USB disk
@rem  Create folders on local (eMMC) disk and copy files from USB disk
@echo *****************************************************************
@echo.
@echo Making directories…
md w:\recycler\scratch
if %errorlevel% NEQ 0 echo "Failed to make w:\recycler\scratch directory" && goto :error
@echo.
md M:\recovery\windowsre
if %errorlevel% NEQ 0 echo "Failed to make M:\recovery\windowsre directory" && goto :error
@echo.
@echo.
@echo *****************************************************************
@echo  Applying the Windows image from the USB
@echo *****************************************************************
@echo call dism /apply-image /imagefile:"%InstallPath%\Install.wim" /index:1 /applydir:w:\ /compact /scratchdir:"w:\recycler\SCRATCH
call dism /apply-image /imagefile:"%InstallPath%\Install.wim" /index:1 /applydir:w:\ /compact /scratchdir:"w:\recycler\SCRATCH
if %errorlevel% NEQ 0 echo "Failed to apply image to w:" && goto :error
@echo.
@echo *****************************************************************
@echo  Rund SingleInstance
@echo *****************************************************************
@echo.
if EXIST W:\Recovery\Customizations\USMT.ppkg dism /Apply-CustomDataImage /CustomDataImage:W:\Recovery\Customizations\USMT.ppkg /ImagePath:W:\ /SingleInstance
@echo *****************************************************************
@rem  Move WinRE to Recovery Partition
@echo *****************************************************************
@echo.
@echo Modifying attributes of winre.wim so we can move it.
attrib w:\Windows\System32\recovery\winre.wim -s -h -a -r
@echo move w:\Windows\System32\recovery\winre.wim M:\recovery\windowsre
move w:\Windows\System32\recovery\winre.wim M:\recovery\windowsre
if %errorlevel% NEQ 0 echo "Failed to move winre.wim to M:\recovery\windowsre" && goto :error
@echo.
@echo reset attributes now
attrib M:\Recovery\Windowsre\winre.wim +s +h +a +r
@echo.
@echo.
@echo *****************************************************************
@echo  Setting the boot environment
@echo *****************************************************************
@echo call w:\WINDOWS\SYSTEM32\BCDBOOT w:\WINDOWS /s s: /f all
w:\WINDOWS\SYSTEM32\BCDBOOT w:\WINDOWS /s s: /f all
if %errorlevel% NEQ 0 echo "Failed to set boot information" && goto :error
@echo.
@echo.
@echo.
@echo *****************************************************************
@echo  Setting the recovery environment
@echo *****************************************************************
@echo w:\windows\system32\reagentc /SetREImage /Path M:\RECOVERY\WINDOWSRE /target w:\windows
w:\windows\system32\reagentc /SetREImage /Path M:\RECOVERY\WINDOWSRE /target w:\windows
if %errorlevel% NEQ 0 echo "Failed to set recovery information" && goto :error

attrib +H +R W:\Recovery
rmdir /s /q w:\recycler
if "%FLASH_BIOS%"=="1" GOTO :FLASH_BIOS
@echo *****************************************************************
@echo  WIMboot image deployment COMPLETE. Type EXIT from Command
@echo  Prompt to restart or turn off device.
@echo *****************************************************************、
Wpeutil shutdown
color 2f
Goto :END

:FLASH_BIOS
@echo.
@echo *****************************************************************
@echo     Flash BIOS
@echo *****************************************************************
@echo.
@echo   BIOS file FOUND at %WinPESource%Images\BIOS\*.ROM
@echo.
xcopy /y %WinPESource%Images\BIOS\*.ROM %WinPESource%Scripts\Tools\
for /r "%WinPESource%Scripts\Tools" %%Z in (*.ROM) do (
  ren "%%Z" "%%~na.fd"
)
if NOT EXIST %WinPESource%Scripts\Tools\*.fd echo "Can not find the BIOS file" && goto :error
@REM Flash BIOS
%WinPESource%Scripts\Tools\H2OFFT-W.exe
Del /q %WinPESource%Scripts\Tools\*.fd
if %errorlevel% NEQ 0 echo "Failed to flash BIOS" && goto :error
@echo *****************************************************************
@echo  WIMboot image deployment COMPLETE. Type EXIT from Command
@echo  Prompt to restart or turn off device.
@echo *****************************************************************
color 2f
Goto :END

:ERROR
@echo.
@echo An error has been detected.
color 4f
@echo.
goto :END

:ListPar
@REM This section is to bring a disk number and use it to List Partitions
@echo.
set TempDisk=%1
diskpart /s x:\Par.txt>x:\ParOutput.txt
for /f "skip=24 tokens=3" %%A in (x:\ParOutput.txt) do (
if /i "%%A"=="no" set Disk=%TempDisk%
)
for /f "skip=26 tokens=4" %%A in (x:\ParOutput.txt) do (
if /i NOT "%%A"=="Winpe" set Disk=%TempDisk%
)
Goto :EOF

:END
@rem
@rem  Get finish time so we can evaluate total WinPE phase time.
@rem
call |time>x:\StopTime.txt
@rem
@rem  Now parse both files to display the Start and Finish Time
@rem
@echo.
@echo.
for /f "tokens=5" %%A in (x:\starttime.txt) do echo Script Start Time is %%A
for /f "tokens=5" %%A in (x:\stoptime.txt) do echo  Script Stop Time is %%A
@echo.
