Tutorial Backup ROM with MTKDroidTools

Author adMember Info


  • Listed by: SoCr@Te
  • Member Since: 05/15/0470



Presumed All Drivers properly set up on Win Machine, All Tolls Downloaded and Extracted in appropriate working folder, full charge the battery of Smart Phone.




MTKDroidTools Version: 2.4.5  here

If Finish Error try with Version 2.4.3 here ( thx info titi27339 )


The tutorial:

1.Device have been rooted by above step
2.Set Device to USB Debugging Enable
3.Go to MTK Droid Tools >Run As Administrator MTK Droid Tools.exe
4.Connect Phone to PC via USB Port



- Green color on device indicator 9300 indicate the devices have been ROOTED (The Color for every computer probably different)

- Click Second Tab : root, backup,recovery



- To do Back up Just Click Back Up Button, by default MTK Droid Tools will back up the whole rom WITHOUT USERDATA
 (everything user setup like google account, email setting, time zone, gmail setting).
 If you want to back up also your peronal setting then Thick Backup User data and Cache, otherwise let it blank

- Option Leave Flash Tools File on SD Card will also store backup file to phone's sd card Suggestion Leave it Blank,
 since storing the file at sdcard probably will fail if sdcard full


5.Once everything satisfying : Click BACK UP Button

- Back up process starting


- It is take a while Just be patient
- Upon nearly finishing Back Up a pop up request appear



- Suggested to click YES, by accepting the option, Tools will archive the whole back up rom into zip file.
 It is easier to be store and upload to internet storage
6.FINISHED …. Back Up file stored into : MTKDroidTools >Backup


7.Suggested To copy backup file and store into other safe folder Just in case


Share Button

※Please make a backup of your device before installing or updating ROM

19 Responses to“Tutorial Backup ROM with MTKDroidTools”

  1. 03/08/2014
    Posts: 1


    I have tried it, the backup has finished. When I open the scatter via sp flashtools, the error occured


    "Access violation of address 5DAA10A0 in module 'FLASHTOOLLIB.dll'"

  2. 08/12/2014
    Posts: 1


    When pop up request appear "Packing backup?"click "NO".
    After that click on "To prepare blocks for Flash Tool ".
    Then choose the file md5 and the rom is ready for the flash tool.

  3. 07/16/2014
    Posts: 1




  4. 09/15/2014
    Posts: 2


    Please i bricked my opsson while changing the fonts anybody with the back up rom or custom rom,your help will be really appreciated.

  5. 09/15/2014
    Posts: 2


    Please i bricked my opsson6622 while changing the fonts anybody with the back up rom or custom rom,your help will be really appreciated.

  6. 11/01/2014
    Posts: 1


     - system.ext4.img –ERROR : /mnt/sdcard/clockworkmod/backup/141102-132251/files/system.ext4.img: write error: No space left on device
     —We keep folders contents copying on PC
      - /data/nvram
      - /system

  7. 05/31/2014
    Posts: 3


    Access violation at address 0FA410A0 in module 'FLASHTOOLLIB>DLL'. Reas of address 00000000

    please help me to solve this error my phone was dead since 6 monts. When i load scatter file in Smart Phone Flash Tool v3.1316.0.150 then i get error.



  8. 12/15/2014
    Posts: 9


    Gracias amigo!

  9. 10/18/2014
    Posts: 3


    Hello friends:
    I try to backup the ROM and I can not for the following messages:
    UbootBuild v. —–You must be ROOT SHELL
    LCD driver IC. —–You must be ROOT SHELL

    as I am new to this stuff, do not know how to solve this problem. Can anyone help? Thank you



  10. 07/14/2014
    Posts: 2


    I have HDC 6592 phone. I have a stock ROM backup. When I make scatter and prepare files for flash tool, it comes up with scatter 6582.

    Also trying CWM recovery restore from ext.sd card, i get md5 missmatch. Help anyone?
