- Title: Unihertz ATom XL 11
- Listed: November, 2024
- Last modified: 01/31/2025 7:06 am
- Version: ROM Android 11
You must be logged for ROM download.
3722 total views, 1 today
2 Total favorites
Member Info
DESCRIPTION
ROM Phone Unihertz ATom XL – ROM Android 11
ONLY MT6771
ROM 2 – Official Unihertz ATom XL Version: Unihertz_Atom_XL_EEA_20230110 – Atom-user 11 – g63v71c2k_dfl_stee_eea – OTA
ROM 1 – Official Unihertz ATom XL Version: Unihertz_Atom_XL_20231110 – Atom-user 11 – g63v71c2k_dfl_stee – OTA
ROM 2 – Official Unihertz ATom XL Version: Unihertz_Atom_XL_EEA_20230110 – Atom-user 11 – g63v71c2k_dfl_stee_eea
ROM 1 – Official Unihertz ATom XL Version: Unihertz_Atom_XL_20231110 – Atom-user 11 – g63v71c2k_dfl_stee
Gapps include – No Rooted
Language support: Multilang
Install ROM :
- Unpack FlashTools, and Click on Flash_tool.exe
- Select "scatter-Loading" and search MT6771_Android_scatter.txt in ROM
- Wait file to be added into Flash Tool
- Select "Download Only" or if upgrade "Firmware upgrade"
- Turn off your phone, remove the battery (if the battery is removable) and replace it after some seconds (and don't turn on the phone).
- Press “Download” button to start
- and connect your phone into the computer via USB data cable.
- The process will start and a red progress bar will appear after color purple, yellow.
- And green circles display
- Finish !
- You can now safely disconnect your phone and turn it on.
※Please make a backup of your device before installing or updating ROM
"MT6771_Android_scatter.txt" doesn't exist in the provided ROM file and choosing he scatter.txt file that is there in the FlashTool result in an error (the scatter file format is invalid; 0xC0030001). Please help!
>>I am using the ROM2-OTA<<
Hi
MT6771_Android_scatter.tx is only for flash not OTA
Thank you for your quick reply. I previously tried to flash a LOS via Windows, then Linux, but it failed at various hurdles and now keep going into a bootloop. I can't power it off and cannot get into any other screen than either the loop of fastboot mode (every once in a while). Now I simply want to get it back working. Do you have any advice? AI tells me about flashing a system.img (which I don't have), and I wouldn't know how to turn it off to follow your instructions (the scatter choosing worked btw).
ok so you must flash your mobile , if europeen you choose EEA
ROM 2 – Official Unihertz ATom XL Version: Unihertz_Atom_XL_EEA_20230110 – Atom-user 11 – g63v71c2k_dfl_stee_eea
use last flashtools V5
Yes, I tried that with the FlashTool V5 and it resulted in a bootloop and error message in the FlashTool, giving TS steps so generic that they are not useful at all (e.g., try another device, try another PC, try another cable, etc.). The in you latest answer linked V6 of the FlashTool has no option for me to select a scatter.txt file at all unfortunately. Also, the only way I get my phone off is by letting the battery drain and use it then in this procedure.
can you try with android 10
I tried Android 10 now, and it results in the same issue unfortunately:
"ERROR : STATUS_PROTOCOL_ERR (0xC0010005)
[HINT]: Please retry the following steps: 1. retry a new cable; 2. retry a new com port; 3. retry a new device; 4. retry another PC; 5. retry pressing download volume down and plug in USB cable."
Error 0xC0010005
Message: BROM ERROR: STATUS_PROTOCOL_ERR (0xC0010005)
Meaning: Sp flash tool is having problems communicating with the device
Solution: Ensure the phone is properly switched off (with battery connected) before connecting to PC for flashing.
The battery is fixed in there, and the only way for me to have the device properly off is by having its battery run out of juice (since otherwise it gets stuck in a bootloop and occasionally in a fastboot mode from which I can only get into the bootloop again). I tried several button combinations and fastboot commands to get the device properly off respectively on to then turn it off, but none work…
Hi
