• Title: STAR N9500
  • Listed: 12/06/2013 3:10 am
  • ROM Version: ROM Android 4.2.1
  • You must be Membership (Account Premium)
    for ROM download.

Overall Rating : 42

67885 total views, 3 today

2 Total favorites


STAR N9500

Author adMember Info


  • Listed by: SoCr@Te
  • Member Since: 05/15/0470


ROM Phone STAR N9500  – ROM Android 4.2.1

Update Official Star N9500 : N9500_20130827_e2006v20_v89_jbaol1 & N9500_20130827_e2006_v89_jbaol1

ATTENTION Version e2006v20_v89 and e2006_v89 ( I don't know why. Maybe another motherboard )


2013.08.28 jinweibo

Compatible with 8825
Compatible 12830
Chinese delete under English interface display
After modifying the camera interpolation 1200W, 500W proactive interpolation

2013.08.23 jinweibo
Open frace version

2013.08.07 jinweibo
Add floating window applications, off by default
Add 12830 camera
Delete Google Pinyin Input Method
Compatible memory Hynix256 +16
Modify distance sensor lights lit problem



Update Official Star N9500 : N9500_20130517_e2006v20_v89_jbaol1


Modify some interface display


Update Official Star N9500 : N9500.20130510_e2006_v89_jbaol1 (Thx anthony) With CWM

Update Official Star N9500 : N9500.20130419_e2006_v89_jbaol1 (Thx perico)

ROM Official Star N9500 : N9500.20130412_e2006_v89_jbaol1


Modify the hands-free calls whistle
Add customers Wallpaper
Compatible with exquisite screen
Update to the latest version

Language support : Multi Lang


Install ROM :

To unpack Flash run Flash_tool.exe
Select a the MT6589_Android_scatter_emmc.txt in ROM
Click Flash_tool.exe interface Firmware-> Upgrade

Phone after taking the battery in put something
Connect the data cable
Brush finished with green circles appears


Install with SP MDT: ( thx palicaj )

Unpack the archive SP_MDT_exe_v3.1304.00_A2013.02.26.rar and archive with the ROM

1). Turn off the smartphone. Cable is not connected to the computer.

2). Remove the battery and insert it again

3). Connect your phone to a computer cable. The operating system detects a new device

4). Disconnect the cable from the computer.

5). Run SPMultiPortFlashDownloadProject.exe

6). Choose Database Factory menu> Configuration File data source and specify the file MTK_DATABASE.mdb (it is in the folder SP_MDT).

7). Choose File> Open File Agent download and specify the file MTK_AllInOneDA.bin (it is in the folder SP_MDT).

8). Click File and select the MT6589_Android_scatter_emmc.txt file (it's in the folder with the rom).

9). choose this options:

Main sensor = ov8825_mipi_raw (back to camera),  Sub sensor = hi253_yuv (front), LCDLT050ANKP019A (display)

10). The other parameters are fixed, as in the screenshot below.

11). Click "Start all".

12). Connect your phone to a computer cable. The program should see and blink. If the phone is not detected, then unplug it from the computer, remove and insert the battery and reconnect it to the computer.

13). After (OK) click Stop and disable any phone.

14). Completed.


※Please make a backup of your device before installing or updating ROM

104 Responses to“STAR N9500”

  1. 04/26/2013


    Tried this, and phone is dead now….
    Flash tool is new, but dont help – i have v3.1304.0.119

    Any info how to unbrick the phone?

  2. SoCr@Te


    you had what rom version before

    • 04/26/2013


      I had 4.2.1,  i think date was : 20130322_e2006_v89_jbaol1
      Now is dead.

      I used SP flash tool v3.1304, (v1252 didnt worked) on win7 x64, run as administrator.
      i select scater loading file, everything looks ok, i click upgrade.
      Everything was ok, at end ar restart, i had blank screen, phone buttons was on, but phone didnt worker. Afret that i tried same way to download older firmware from this site and… process stopped in the middle. with error.

      Flash tool find the phone as MTK USB port, but then after try to upgrade first thing i get error BROM ERROR: S_FT_ENABLE_DRAM_FAIL (4032) – [EMI] Enable DRAM Failed!

      Phone do not react holding together  volume up + power or volume down + power
      With battery computer recognize it as MTK USB Port (on usb2 or usb33 …)

  3. SoCr@Te


    I'll try to find you another rom.

  4. 03/18/2013

    United Arab Emirates

    I made the same stupid mistake (clicked upgrade)

    I should have clicked download maybe ?!


  5. 04/14/2013


    Same error here with an other phone (S_FT_ENABLE_DRAM_FAIL (4032)).

    Recognize by windows like a MTK port without battery …

  6. 04/26/2013


    With this linked flashtool v3.1252 i think is not possible to upgrade N9500 – i get error S_UNSUPPORTED_VER_OF_DA (1022), because of that i used flash tool v3.1304 (whis is from end of jan 2013) here i get error S_FT_ENABLE_DRAM_FAIL (4032) . But my phone is still bricked…. I think N9500 is produed from mar.2013, so maybe is somewhere flastool from march to work better with n9500?  (what exactly mean download agent in flashtool?)

    I also got my phone to be recognized as DA USB VCOM Port, but here SPFlash tool dont start any action… just waiting (searching).

    Also this new ROM from 2013-04-19 dont repair phone, here is even older flashtool v3.1216 whic do not reocgnize scatter file

    Anyone have any advice how to make phone alive?


  7. 04/26/2013


    I rescue my phone.
    - i downloaded from this site firmware for Star S5 with the name Root_DelChina_MP_mt89_v9_c05_pulid_jb2_20130321-160914_PC

    - i used SPflash tool v3.1304.0.119
    - Phone with no battery , disconected.
    - start flash tool, select scatter file srom s5 rom directory
    - i clicked "dowload"
    - I connected the phone
    - flash tool did something, and in ca 3-5 second i got warnint that is better to clikc  "Firmware update" so i cliked this firmware update
    - disconect phone from USB , and connect it agani
    - flash tool started to flash the phone !!!! (no error DRAM_FAIL!!!)
    - everything went ok, flash completed.

    I tried to run the phone, but screen just turned on back light and of and on …
    So… i tried new flash with correct rom for N9500 – downloaded here with date 2013-04-19, and process started!!! no error, finished. Disconnect the phone, put the battery on, i put the phone to the charger (i was not sure how is battery) and luckily i have working phone.

    Thanx to SoCr@Te for ROM – this one works !!

  8. 04/26/2013


    camera dont work!

  9. 04/26/2013


    I fix the camera, in ROM is not selected ok.
    I took SP multi port download tool and i changed sensors to:

    screen: LT050ANKP019A
    main sensor: ov8825_mipi_raw
    sub sensor: hi253_yuv

    Then i "downloaded" with flash tool only UBOOT (file lk.bin – which was changed), and now phone works with booth cams.

  10. 03/20/2013


    Work mee to this system!! thx at socr@te and palicaj
